MATERIAL:
PUSH PLASTIC
MATERIAL DETAILS:
PLA
DIMENSIONS:
11" X 5" X 16"
WEIGHT:
3.2 KG
PRINT TIME:
13 Hours
Composite Intake Manifold
Material brand: Techmer Electrafil® J-50/CF/10.
Material Details: Polycarbonate /10% long fiber carbon fiber
Dimensions: 22" x 12" x 8"
Weight: 2.0kg
Print Time: 13 hours
Print Settings: .37mm layers - 2500mm/min - 1mm nozzle
Application: Intake Manifold Flow Test
Composite Thermoforming Mold
Material brand: Techmer Electrafil® J-50/CF/10.
Material Details: Polycarbonate /10% long fiber carbon fiber
Dimensions:
3" x 6" x 8"
Weight:
.43kg
Print Time:
7 hours
Print Settings: .4mm layers - 2500mm/min - 1mm nozzle
Application: Vacuum thermoforming mold.
Composite Nosecone Layup Mold
Material brand: Techmer Electrafil® J-50/CF/10.
Material Details: Polycarbonate /10% long fiber carbon fiber
Dimensions: 12" x 6" x 3"
Weight: 1.2kg
Print Time: 8 hours
Print Settings: .4mm layers - 2300mm/min - 1mm nozzle
Application: Vacuum thermoforming mold.
Trex Head
Helix
Material brand: Push Plastic
Material Details: PLA
Dimensions: 27" x 8" x 8"
Weight: 3.0kg
Print Time: 17 hours
Print Settings: .4mm layers - 3000mm/min - 1mm nozzle - 250°C
Application: Fluid flow turbulence test
Rocket Nozzle
Material brand: Push Plastic
Material Details: PLA
Dimensions: 34" x 13" x 13"
Weight: 1.5kg
Print Time: 8 hours
Print Settings: .4mm layers - 3500mm/min - 1mm nozzle - 250°C
Application: Vase test
Twisted Vase
Material brand:
Breathe-3dp
Material Details: PLA++
Dimensions: 35" x 6" x 6"
Weight: 3.0kg
Print Time: 24 hours
Print Settings: .4mm layers - 3000mm/min - 1mm nozzle - 240°C
Application: Surface finish test
Coke Bottle
Material brand: Push Plastic
Material Details: PLA
Dimensions: 32" x 7" x 7"
Weight: 2.5kg
Print Time: 13 hours
Print Settings: .4mm layers - 3100mm/min - 1mm nozzle - 230°C
Application: Trade Show Demo
Giant Bolt
Material brand: Push Plastic
Material Details: PLA
Dimensions: 33" x 8" x 8"
Weight: 4.0kg
Print Time: 30 hours
Print Settings: .4mm layers - 2700mm/min - 1mm nozzle - 230°C
Application: Just for fun
Nose Cone
Material brand: Push Plastic
Material Details: PLA
Dimensions: 18" x 8" x 7"
Weight: 1.5kg
Print Time: 6 hours
Print Settings: .38mm layers - 2600mm/min - 1mm nozzle - 220°C
Application: Mold Test
Table Leg
Material brand: Push Plastic
Material Details: PLA
Dimensions: 35" x 20" x 20"
Weight: 2.5kg
Print Time: 13 hours
Print Settings: .4mm layers - 3400mm/min - 1mm nozzle - 240°C
Application: Mold for concrete casting a table leg.
3d scanned head
